The Solar System



Other Planets and the Earth



New Solar System



The Earth is one of a family of eight planets.  All of these are orbiting round the Sun.  Together with the Sun and the 8 planets makes our Solar System.  All eight planets are different in every respect.  For example, in shape, size and conditions.  The distances between the planets are enormous; much farther than the picture on the top of this page.

Click here to see the Solar System.



Inner Planets

Mercury

Venus

Earth

Mars

Asteroids

Distance from the Sun (million Km)

60

110

150

230

-

Time to Travel once round the Sun ( Earth years)

0.2

0.6

1

2

-

Diameter (Km)

5000

12000

12800

7000

-


Outer Planets

Jupiter

Saturn

Uranus

Neptune

Distance from the Sun (million Km)

780

1400

2900

4500

Time to Travel once round the Sun ( Earth years)

12

30

84

160

Diameter (Km)

140000

120000

52000

50000

In addition to these 8 planets are 3 smaller dwarf planets. As of August 24, 2006, Pluto was no longer considered a planet and is instead described as a Dwarf Planet.

Dwarf Planets

Eris

Ceres

Pluto

Distance from the Sun (million Km)





6000

Time to Travel once round the Sun ( Earth years)





250

Diameter (Km)





3000



Try these questions!

You could use the table above to answer the following questions.

Q1.  How long does it take for the Earth to orbit round the Sun once?

Q2.  Which heavenly body is bigger, the Sun or the Earth?

Q3.  Which planet is the smallest

Q4.  Which planet is biggest?

Q5.  Which planet is the coldest?

Q6.  Which planet is farthest from the Sun?

Q7.  Which planet is nearest to the Sun?

Q8.  Which planet has large rings?

Q9.  Which planet is Approximately the same size as the Earth?

Q10.  Name all the planets which are larger then the Earth?

Q11. Which is the hottest planet?

Q12.  Which planet comes between Jupiter and Earth?

Q13.  Which planet takes the shortest time to orbit the Sun once?

Q14.  What trend can you see between the time for one complete orbit and the distance from the Sun?

Q15.  What do you find between Mars and Jupiter and what are they?

Q16.  What pattern can you see between the surface temperature and the distance from the Sun?

Q17.  What keeps the planets in their orbit around the Sun?

Q18.  Name the shape of the orbit that planets move round the Sun?

Q19.  State the names of 4 inner planets?

Q20.  Why is the temperature higher on these 4 inner planets than the 5 outer planets?

Q21.  Does the Sun look bigger from Pluto or Mercury?

Q22.  Why was Pluto the last planet to be discovered?



Click here for answers!



Click here to take an interactive Solar System Quiz



Our Solar System - Consists of 8 Planets

Mercury - Venus - Earth - Mars - The inner planets

The four inner planets are all made of rocks and have metallic cores.  Our Earth is the largest of these inner planets.

Mercury:  this is the smallest planet, roughly the size of our moon and is closest to the Sun.  Its mass is not great enough to produce a strong gravitational field and for this reason it is unable to sustain atmosphere. The gases just simply drift into space.  The side of Mercury facing the Sun can reach temperature high enough to melt lead (430ºC), while the dark side drops to -170ºC.

Mercury

Venus

Venus It is almost the same size as the Earth.  It is an unpleasant planet.  It has a rocky surface, covered by dense clouds of sulphuric acid and carbon dioxide.  These clouds of gas entirely hide the surface of Venus. This traps the Sun's heat due to the ' Super Greenhouse Effect' and for this reason it surface temperature is higher then that of Mercury (approximately 500ºC).  Without this atmosphere, Venus' temperature would be a lot lower.  It reflects a lot of light, so Venus looks bright.  It is also known as the 'Morning and the evening Star'.

Earth:  If you view the Earth from space, it looks blue with swirls of clouds.  Its surface is rocky, with mountains and canyons, which are covered with water and ice.  It is the only planet with water, oxygen and living thing.  Planet Earth has just the right conditions for life to exist, because it is at the right distance from the Sun.  It has one moon.  No doubt, other stars in the universe might have planets with the same life sustaining conditions.

Earth

Mars

Mars:  It is called the red planet.  It is dry cold desert of red rock, with massive mountains and canyons.  It is most like Earth.  It has a thin atmosphere of carbon dioxide (95%), nitrogen, oxygen, water vapour and noble gases.  there is no life on it.  It has 2 small moons.  The dark patch is a giant volcano.

- Saturn - Uranus - Neptune - The outer planets

Jupiter: The largest of the planets and the coldest.  It has no solid surface, it is a liquid giant.  It is made up of mainly liquid hydrogen and helium,  surrounded by these gases and clouds.  The bands of colour , in Jupiter are produced by different regions in the atmosphere.  The great red spot is thought to be an area where the atmosphere constantly swirls around a giant storm.  This spot is 3 times the size of Earth. Jupiter is surrounded by 16 moons.

Jupiter

Saturn

Saturn:  A gas giant, very much like Jupiter.  It is made mostly of hydrogen and helium. It has the most striking ring system of all the outer planets.  The 18 rings are made from billions of tiny particles of rock and ice.  They are held together in orbit by the pull of Saturn's gravity.  It has 18 moons.

Uranus: Another gas giant, made up of hydrogen and helium.  It is different from other planet, because it is lying on its side as it goes round the Sun.  The spin axis of Uranus is tilted at 98°, so that at times it poles point towards the Sun, giving rise to extreme seasons.  It has 15 moons and 11 rings.

Uranus
Neptune

Neptune: Appears in the sky as tiny blue-green speck, using even the most powerful telescope on Earth, because it is so far away from the Sun, where the light is one thousandth as strong as on Earth. Neptune is a ball of water and rock, consisting of atmosphere of hydrogen, helium and methane.  The great dark spot is a storm, about the size of Earth.



Five Dwarf Planets



In addition to the 8 planets are 5 smaller dwarf planets (which are too small to be considered planets). These are Pluto, Eris, Haumea, Makemake and Ceres. As of August 24, 2006, Pluto was no longer considered a planet and is instead described as a Dwarf Planet.



Image showing the five dwarf planets. From left to right: Pluto, Eris, Haumea, Makemake, Ceres.



Pluto: The smallest and the outer most of all the planets, discovered in 1930.  It is of low density, composed of rock and ice, with frozen methane on its surface and thinly spread in the atmosphere.  Pluto's elliptical orbit occasionally takes it within the orbit of Neptune.  It has one moon.

Pluto





My Very Easy Method Just Speeds Up Naming

Learn this line to remember the names of the 8 planets.

Summary of data on planets.



Planets Diameter (Km) Distance from Sun (Km) Time for one orbit (planet's year - relative to Earth) Time for one spin (planet's day - relative to Earth) Average temperature - side facing the sun (ºC) Moons & rings
Mercury 5000 60 88 days 1400 hours +430 0
Venus 12000 110 220 days 5800 hours +470 0
Earth 12800 150 356 ¼ days 24 hours +20 1
Mars 7000 230 2 years 25 hours -20 2
Asteroids
Jupiter 140000 780 12 years 10 hours -150 160
Saturn 120000 1400 30 years 10 hours -180 18 + 18
Uranus 52000 2900 84 years 17 hours -210 15 + 11
Neptune 50000 4500 160 years 16 hours -220 8



Continue... Beyond our Solar System
